Faster git clones with sparse checkouts

  • ・
Thumbnail

We at REKKI are working on a monorepo that contains all the backend Go code for most of our services and jobs. As time goes by and the size of this repository grows, the time it takes for an initial clone becomes noticeable. While this is not really a problem on the engineers’ workstations as they operate statefully, it impacts stateless systems that have to download the codebase regularly: like CIs, CDs, or even our in-house CLI.

Our CLI sometimes needs to pull a fresh version of a specific commit from the Go codebase to perform beta updates when our engineers request it (e.g.: to test new features that are not yet released in the stable version). Cloning the Go monorepo every time they want to install a beta update is not an option, as it takes more than a minute on a good connection.

Shallow clones

The first approach you often take in a situation like this is to shallow clone. While a default clone will fetch all the commits and all the blob objects for the branch you track (by default master/main), a shallow clone will only fetch the blob objects for a subset of these commits, thus resulting in faster clone times.

That is very common in the world of CIs. For example, both GitHub Actions and Travis CI do it by default.

One way you’d do a shallow clone is by specifying the --depth=<n> flag to the git clone command, hence limiting the number of commits to pull starting from the HEAD:

# fetch the latest commit
git clone --depth=1 git@github.com:rekki/go.git

Another way to shallow clone it is to specify a start date instead of a number of commits. This is possible via the --shallow-since=<date> flag with either an absolute or a relative date:

# fetch the last day of commits
git clone --shallow-since='1 day' git@github.com:rekki/go.git

While shallow clones work well in some contexts, they fall short by downloading all the blob objects in the working tree for the given commits. So even specifying a depth of 1 results in non-negligible clone times for some repositories (in the case of our Go monorepo, this still takes 30 seconds).

Sparse checkouts

Another way to reduce the amount of downloaded data is to use sparse checkouts. Sparse checkouts solve that problem by allowing to partially checkout a working tree. While shallow clones give you control over the commits you want to fetch, sparse checkouts will enable you to specify the blob objects you wish to fetch.

While sparse checkouts exist since git 2.25.0, they are still considered experimental. It is unlikely that the feature will be removed in the future, but breaking changes might happen in both its implementation and its usage.

You can either specify a list of directories (in what’s called cone mode) or a list of patterns (ala .gitignore). The manual recommends using the cone mode for performance reasons.

Leveraging sparse checkouts allows you only to fetch the blob objects you need for the task you want to perform. In our case, we wanted only to clone the files required to build our CLI. This is how we did it:

git clone --filter=blob:none --no-checkout git@github.com:rekki/go.git
cd go
git sparse-checkout set --cone go.mod go.sum cmd/rekki-cli pkg/rekki/errors
git checkout master

Let’s explain step by step:

  1. git clone: like a typical clone, but with 2 additional flags:
    • --filter=blob:none: instructs not to fetch any blob object
    • --no-checkout: instructs not to automatically checkout HEAD
  2. git sparse-checkout set: enables the sparse checkout settings and specifies which files should be checked out. Change this line to whatever works for you.
  3. git checkout master: checkouts the actual branch or commit (in this case, the master branch) and fetches the objects matching the sparse patterns.

You can easily adapt these commands to your use cases.

This approach allowed us to reduce the end-to-end time to clone to less than 5 seconds. We are satisfied with that number, and we know that time will only grow proportionally to the size of the code required to build the CLI (and nothing else). So it should stay fast for the foreseeable future.

Conclusion

Using sparse checkouts is a bit more involved in the commands you have to execute, but it allows for more control over the files you download on your local filesystem. You don’t always need the entirety of a git repository, and sparse checkouts allow you to pick what you need granularly.

Give it a try the next time you find yourself in a situation where a git clone takes too long. What use case do you have in mind? Leave a comment with your ideas below.
